Blast Cabinet, Shop-Mate 2648, filter bag dust collector

Description

The Shop Mate is a hopper suction feed entry-level intermittent-use cabinet featuring a 48" wide x 26" deep x 26" high working chamber with dual side doors, and flip up front access panel for loading heavy parts. A 120 cfm dust bag drum collector optimizes visibility inside the cabinet while blasting.

Although the Shop Mate does not have a media reclaimer, it has a spring-operated quick-drain hopper designed to accommodate a standard-size 5-gallon bucket. This feature makes disposing of worn-out media a quick, simple, and clean process. Optional drum-liner bags ease the disposal process.

The Shop Mate comes with a No. 4 BNP Gun with a 5/16" orifice ceramic nozzle, but can be used with long-wearing tungsten-carbide or boron-carbide nozzle when aggressive media is used.

A conveniently located easy to use lens-on-a-roll prolongs the life of the view window glass, protecting its interior surface.

Blast Gun: No. 4 BNP Gun with 5/16" orifice ceramic nozzle
Air Consumption: 21 cfm @ 80 psi
Electrical: 115V, 1PH, 60Hz
Reclaimer: 120 cfm dust bag in drum
Cabinet Work Grating: 500 lb Uniform Load
Amp Draw: 8

Working Chamber Size:
48: wide (1219 mm)
26" deep (648 mm)
26" high (711 mm)

Viewing Area:
18.5" wide (483 mm)
10.5" height (197 mm)
